Factory interactive touch display android 11.0 smart board with type C port
1. 4K Ultra HD resolution.
2. High precision 20 points IR touch.
3. Built-in 12 MP camera and 6-array digital pickup microphone.
4. Support Android and Windows system.
5. Numerous HDMI, VGA, USB and multimedia ports.
6. High performance modular design.
7. Wireless screen transmission, multi-screen interaction, one-key projection, two-way control, to achieve content sharing between multiple terminals
8. 60,000 hours of reliable use.
Functions: 20point touch, 10point writing, 2points zoom/drag, gesture erase (hand back erase). Annotation function: making annotations on-screen or during the presentation. Digital whiteboard function: insert and edit files, pictures, making notes, etc. Scan QR code to share annotation/memos. Wireless projection: share laptop, mobile screens to touch screen interactive flat panel without cable, just one click of wireless screen dongle. OPS computer: OPS slot-in, support i7, i5 processor Windows system. A quick switch from Android system to the Windows system. Touch USB, USB, HDMI, etc multi-input and output ports. Can connect with the video camera, wireless microphone for video conference system.
Related Products
⚙️ Specifications
Model |
HS-EHY65/HS-EHY75/HS-EHY85/HS-EHY86 |
Product name |
Interactive whiteboard for conference/classroom |
Display parameters
|
|
Size |
65 inch/75 inch/85 inch/86 inch |
Resolution |
3840*2160（RGB）/4K |
Brightness |
≥350cd/㎡ |
Contrast ratio |
5000:1 |
Response time |
6.5 ms |
Refresh rate |
60Hz |
Viewing angle |
178°（H）/178°（V） |
Pixel pitch |
0.372*0.372mm |
Android system information
|
|
System version |
Android 11.0 |
RAM |
4GB/8GB |
ROM |
64GB/128GB |
System language |
Chinese Simplified, traditional Chinese, English, Japanese, Russian, German, French, Polish, Spanish,Portuguese, Korean, etc. |
Power information
|
|
Input voltage |
AC：90V～264V |
Frequency range |
50Hz/60Hz |
Maximum power |
≤160W |
OPS power |
DC：19V/5A |
Standby power |
＜0.5W |
Input ports
|
|
TYPE-C port |
*1 |
DP port |
*1 |
PC-RGB port |
*1 |
PC-Audio port |
*1 |
USB3.0 port |
*2 |
HDMI |
*2 |
TF slot |
*1 |
RS232 port |
*1 |
RJ45 |
*1 |
OTG port |
*1 |
Output ports
|
|
TOUCH out |
*1 |
Earphone out |
*1 |
SPDIF out |
*1 |
Other function
|
|
OPS slot |
*1 |
Antenna |
*1 |
Front ports/interfaces
|
|
USB 2.0 |
*1 |
USB 3.0 |
*1 |
Type C |
*1 |
HDMI |
*1 |
Metal switch |
*1 |
Built-in speaker |
20W*2 (Hi-fi speaker) |
Built-in camera |
13MP |
Built-in microphone |
8-way array microphone |
Magnetic pen area |
*1 |
Working environment
|
|
Working temperature |
0℃～50℃ |
Working humidity |
20%～80% |
Working altitude |
≤5000m |
Storage temperature |
-10℃～60℃ |
Storage humidity |
20%～80% |
Appearance information
|
|
Frame/back shell |
Aluminum alloy shell material, in black |
Anti-glare tempered glass |
4mm anti-glare tempered glass |
VESA hole |
4*M8 screw hole/ 500mm*400mm |
Touch parameter
|
|
Touch type |
Infrared touch |
Writing surface material |
4mm anti-glare tempered glass |
Maximum touch points |
20 points |
Response speed |
＜8ms |
Touch accuracy |
The accuracy of 90% center area is ±1mm, 10% edge area accuracy is ±3mm. |
Touch count |
Unlimited times |
Writing mode |
Finger, touch pen, or other non-metallic objects that are not sharp |
Report resolution |
32768*32768 |
Anti-light performance |
＜80000Lux |
System compatibility |
Windows7 and above; Andirod; Linux, Mac |
Palm erase |
Yes |
Plug and play |
Yes |
Drive method |
Free drive |
Communication type |
USB |
Camera parameters
|
|
Pixel camera |
13 MP |
Support maximum resolution |
3840*3104 (15fps) |
Support other resolutions |
1920*1080（30fps); 2592*1944（30fps); 3264*2448（30fps）; 3840*2160（30fps） |
System compatibility |
Windows7 and above; Andirod7.0 and above |
Lens structure |
5P+IR |
Filter |
650±10nm |
Angle of view |
94° |
Wide dynamic |
Support |
Beauty fine adjustment |
Support |
Automatic gain |
Support |
Fill light fine-tuning |
Support |
Communication type |
USB |
Microphone parameters
|
|
Microphone type |
Linear Isometric Array Microphone |
Number of microphone |
8-way array microphone |
S/N ratio |
64dB |
Adapterization distance |
10m |
Sampling Rate |
16KHz |
Sampling bits |
16bit |
Echo cancellation |
Support |
Beamforming |
Support |
Environment restraint |
Support |
Dereverb |
Support |
Sound source localization |
Support |
System compatibility |
Windows7 and above; Andirod7.0 and above |
Communication type |
USB |
OPS
|
|
Slot size |
194mm(L)*181.5mm(W)*33.5mm(H) |
Support OPS size |
195mm(L)*180mm(W)*42mm(H); 195mm(L)*180mm(W)*33mm(H); 195mm(L)*180mm(W)*30mm(H) |
Support power |
≤19V/5A |
Pin Agreement |
80-pin/Intel OPS standard protocol |
Pin contains definition |
Power supply, HDMI/DVI, USB, UART, OPS etc. |
Best resolution |
3840*2160 |
Maximum refresh rate |
60Hz |
OPS configuration |
i3/i5/i7 (optional) |
List of package
|
|
65/75/86 inch interactive whiteboard |
1pcs |
Remote control |
1pcs |
3m power cable |
1pcs |
Touch pen |
2pcs |
Wall mount |
1pcs |
Manual |
1pcs |
🤝 Supports
FAQ
Q: Is your company a real manufacturer?A: Yes, sure. We are the professional manufacturer in Guangming district, Shenzhen city, welcome to visit our factory
anytime.
Q:Can you provide OEM service for the all in one smart interactive whiteboard?
A: Yes,well supported.We can customize it according to your requests.
Q:Do you have stock?
A:We keep 2000 units in Stock every single Month.
Q: How is the quality of the product?
A: We have a dust-free workshop, all our products have been strictly tested high quality by QC before shipping to customers. We have two brand brands in China: "FVASEE" and "HSCHN", "FVASEE" is the top 5 brand in China, quality is the first thing for us!
Q: How can I trust your product quality?
A: We have more than 10 years export experience. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by CE/ROHS/FCC etc.
Q: Does the product only use for school?
A: Yes, our products are widely used in Hospital, School, office etc.
Q: What's your after-sale service?
A: 2 years warranty on parts is provided under normal use. If any defects happen during the period, please send us the details and you will get our reply within 24 hours. Solution will be offered instantly. If necessary, spare parts for free can be provided.
Q:Do you have stock?
A:We keep 2000 units in Stock every single Month.
Q: How is the quality of the product?
A: We have a dust-free workshop, all our products have been strictly tested high quality by QC before shipping to customers. We have two brand brands in China: "FVASEE" and "HSCHN", "FVASEE" is the top 5 brand in China, quality is the first thing for us!
Q: How can I trust your product quality?
A: We have more than 10 years export experience. From material purchasing to product delivery, we have own professional staff and procedures to prevent potential quality risk. Our products have been approved by CE/ROHS/FCC etc.
Q: Does the product only use for school?
A: Yes, our products are widely used in Hospital, School, office etc.
Q: What's your after-sale service?
A: 2 years warranty on parts is provided under normal use. If any defects happen during the period, please send us the details and you will get our reply within 24 hours. Solution will be offered instantly. If necessary, spare parts for free can be provided.
