75 inch interactive flat panel for business HS-FHY75
• 4K Interactive Display with 50 points touch.
• Android 13.0 system with built in applications for leading meetings interactively with the audience.
• Wired and Wireless Networking, Bluetooth 5, Wi-Fi 6 (2.4GHz + 5GHz), NFC (Optional)
• With plenty ports of USB, HDMI,video, network and wireless connectivity.
• Screen-share software for wireless two way touch with up to 8 devices on the screen at the same time.
• Includes heavy duty wall mount for fast deployment.
• Unique 20W built-in speaker and 25W , Built-in microphones powerful with noise reduction.
• With reduces blue light emission for less eye fatigue.
Place of Origin: Shenzhen, China
Brand Name: FVASEE
Certification:ENERGY STAR, CCC,FCC,CB,CE,ROHS,ISO9001,etc.
Model Number: HS-FHY75
Minimum Order Quantity: 1 Piece
Price: $5000.00 – $10000.00
Packaging Details: high quality 3cm thickness honeycomb box (air shipment standard)
Delivery Time: Shipped 30 days after payment
Payment Terms: L/C, T/T, Western Union, etc.
Supply Ability: 1000 Piece/Pieces per Week
F series touch interactive all-in-one whiteboard
Products that combine large-size monitors and multimedia equipment to make meetings more efficient and convenient.F series touch interactive all-in-one whiteboard
Products that combine large-size monitors and multimedia equipment to make meetings more efficient and convenient.1.FVASEE F series interactive multi-touch screen all-in-one whiteboard adopts the principle of infrared emission and blocking to transform a large-sized display (LCD/PDP/rear projection) into a large-scale interactive touch display device.It is a new type of all-in-one (TV, computer, advertising machine, projector, electronic whiteboard, audio, etc.) touch multimedia teaching conference solution.
2.FVASEE Technology Co.,Limited established in 2011 is one of the leading and professional manufacturers of touch digital displays in China. FVASEE manufactures interactive whiteboards, digital touch screens, digital nano blackboards, advertising machines, digital signs, etc.
3.Automated dust-free workshop of FVASEE. It has become the ODM/OEM partner of several world class enterprises. FVASEE series products have passed ENERGY STAR, CCC, CE, FCC, RoHS and other certifications.
Smart whiteboard writing
Built-in electronic whiteboard software to meet various needs such as conference training and teaching.
Online remote video conference
Video conferencing enables the same screen to overcome geographic barriers, no matter where you are. Support wireless two-way touch.Support wireless projection system
The smart screen projection system enable mobile phones,tablets and computer to achieve smart wireless screen share fuction.
Support scan share function
You can easily save and share meeting content through the mobile phone scan code or email.It makes conference more easier.Unique energy-saving design
Unique one-key energy saving button and the function of tapping the screen to wake up the machine. It has the characteristics of low power consumption, low radiation and energy saving.
⚙️ Specifications
| Display parameters | ||
| Screen size | 75 inch DLED panel,IPS technology | |
| Screen Resolution | 3840*2160(RGB)/4K | |
| Brightness | ≥350cd/m² | |
| Contract | 6000:1(Typ.) | |
| Response time | 6.5ms | |
| Refresh rate | 60Hz | |
| View angle | 178°(H)/178°(V) | |
| Display area (W*H mm) | 1650.24(W)*928.26(H) | |
| Android system information | ||
| system version | Android 13-Upgradable | |
| CPU Architecture | A55 | |
| CPU main frequency | 1.2GHz | |
| CPU cores number | Eight-core | |
| GPU | ARM Mali-G52 MP2(2EE) | |
| Running memory | 8 GB | |
| Storage memory | 128 GB | |
| System language | Multi-language support including English,Spanish. | |
| Power supply | ||
| Input voltage | AC:90V~264V | |
| Frequency Range | 50Hz/60Hz | |
| Total power | 285W | |
| OPS power | DC:19V/5A | |
| Standby power | <0.5W | |
| Port function information | ||
| HDMI IN | *3 | |
| USB 2.0 | *1 | |
| USB 3.0 | *1 | |
| TF Card | *1 | |
| TYPE-C input | *3 | |
| DP input | *1 | |
| RJ45 cable input | *1 | |
| AVInput | *1 | |
| VGA Input | *1 | |
| VGA audio input | *1 | |
| MIC input | *1 | |
| AV out | *1 | |
| Y-PB-PR port | *1 | |
| Touch Output | *1 | |
| HDMI 2.0 Output | *1 | |
| EARPHONE OUT | *1 | |
| RJ45 cable output | *1 | |
| RS-232 | *1 | |
| COAX OUT | *1 | |
| OPS slot | *1 | |
| Pre-function information | ||
| Shared USB | *2 | |
| USB Touch Out | *1 | |
| TYPE -C input | *1 | |
| HDMI IN | *1 | |
| Metal switch | *1 | |
| Front built-in speakers/20W | *2 | |
| 25W subwoofer | *1 | |
| Eight-array integrated microphone with noise cancellation | *1 | |
| Front Magnetic pen area | *2 | |
| Environmental factor | ||
| Standard operating temperature | 0 C~ 4 0 C | |
| Standard working humidity | 20% ~ 80% | |
| Standard working altitude | ≤5000m | |
| Standard storage temperature | - 1 0 C~ 6 0 C | |
| Standard storage humidity | 20% ~ 80% | |
| Useful life | ≥100,000 hours | |
| Appearance information | ||
| Frame/back shell | Frame: Aluminum Profile/Black Brushed; Back Shell: Sheet Metal/Black | |
| Tempered glass | 4mm thickness/anti-glare/Mohs 9H | |
| VESA Hole (mm) | 600*400 | |
| NW | 56±0.5 KG | |
| GW | 70±0.5 KG | |
| Product Size(mm) | 1708*1026*92mm | |
| Package Size(mm) | 1866*230*1186mm | |
| Touch parameter | ||
| Touch type | Infrared touch frame | |
| Writing surface material | 4mm AG tempered glass | |
| Writing points | 50 points | |
| Reponse time | ＜6.5ms | |
| Touch accuracy | The accuracy of 90% central area is ±1mm, and the accuracy of 10% edge area is ±3mm | |
| Hit counts | Unlimited | |
| Notation | Fingers, special writing pens, or other non-metallic objects that are not sharp | |
| Report resolution | 32768*32768 | |
| Light resistance | ＜80000Lux | |
| System compatible | Windows7and above；Android；Linux 、Mac | |
| Palm erasure | Support | |
| Plug and Play | Support | |
| Drive mode | Free drive | |
| Communication type | USB | |
| Ops slot specification | ||
| Processors | Intel 9 11 Generation Core CPU | |
| System | Windows 11 Home, pre-installed system, | |
| Storage | 16 GBRAM (with capacity increase slot) and 512 GB SSD | |
| Slot size | 194mm (L) *181.5mm (W) *33.5mm (H) | |
| Support OPS max size | 195mm (L) * 180mm (W) *42mm (H)； 195mm (L) * 180mm (W) *33mm (H)； 195mm (L) * 180mm (W) *30mm (H)； | |
| Support power | ≤19V/5A | |
| Pin protocol | 80-pin/Intel OPS standard protocol | |
| Rear interfaces | 1*HDMI Output 1*DP Output 1*MIC output 1*Audio output 1*RJ45 Gigabit Etherent port 4*USB 3.0 TPYE-A 2*USB 2.0 TYPE-A 1* One-Click Restore button 2*antennas | |
| Max resolution | 3840*2160 | |
| Max Refresh rate | 60Hz | |
Specification: 75 inch interactive flat panel for business HS-FHY75
|
Videos: 75 inch interactive flat panel for business HS-FHY75
🤝 Supports
Downloads
FAQ
1.Q:I haven't done business with you before,how can i trust your company?
A: We are a 11-year OEM/ODM factory for digital touch system products.
what's more,we've got quite a lot authority certificates,for example,CE,CCC,UL,RoHS, ISO9001, ISO14001 certificates.
2. Q:what's the shipment terms and delivery time of your company?
A:Well, they depends on the quantity of your order.As you know ,we need time to manufacture the machines.but mostly,
the shipment time is 3-8 working days after delivery.
For Delivery way, for Sample and Bulk order < 100KG, we will kindly suggest Express and Air freight, when Air freight and
Sea shipping for Bulk order >100KG.As for detailed cost, it depends on your final order.
3.Q:How long is the warranty time for your products?
A:We can offer 100% guarantee on our product. Our officially promised warranty time is one whole year after delivery at best.
4.Q: What are your advantages?
A: 1) We specialize in the research, production and sales ,so our price is reasonable and our service is professional .
2)10 fingers can write simultaneously on our IR touch screen display, built-in OPS PC, and free whiteboard software,
at the same time, owns CE ISO9001 ISO14001 3C CE certificates etc.
3)Low defectives and timely service. The defectives of our products seldom appear ,
if quality problem, we give spare part or new replacement free of charge.
5.Q:I would like to ask you if it's possible to have my logo on the product.
A:We hope you know that our company Fvasee perfectly support customized logo service. But, we also
hope you know that it's an extra-service,so a little bit extra service fee is needed.
